Dexter Laundry T650 - Chassis and Drain Part # by Model

Key Description T650 T750 T950 T1450 QTY
1 Base Assy,Frame 9945-143-002 9945-112-002 9945-128-002 9945-133-002 1
2 Outer Tub Assy 9930-167-001 9930-148-001 9930-156-001 9930-155-001 1
* Tub & Cylinder Assy 9869-035-001 9869-025-002 9869-027-002 9869-026-001 1
3 Tub Front 9974-014-001 9974-011-001 9974-011-002 9947-012-001 1
* Gasket, Tub Front 9206-421-004 9206-421-002 9206-421-002 9206-421-002 1
4 Ring Assy, Tub Mtg-Front Clamp 9950-063-001 9950-055-001 9950-055-001 9950-061-001 1
5 Bolt, Top Front Ring 3/8”-16 x 3” 9545-029-009 9545-029-009 9545-029-009 9545-029-009 1
6 Nut WCAD 3/8”-16 8640-415-001 8640-415-001 8640-415-001 8640-415-001 1
7 Bolt, 1/2” -13 x 2” (Tub Mounting
to Frame)
9545-017-013 9545-017-013 9545-017-013 9545-017-013 2
8 Nut, Wizloc 1/2” x 13 8640-417-005 8640-417-005 8640-417-005 8640-417-005 2
9 Washer, Flat 1/2” 8641-581-026 8641-581-026 8641-581-026 8641-581-026 2
10 Hose, Tub to Drain Valve 9242-464-001 9242-456-001 9242-456-001 9242-459-001 1
11 Clamp, Hose (Tub to Drain Valve) 8654 -117-014 8654-117-014 8654-117-014 8654-117-008 2
12 Valve, Drain 9379-202-001 9379-202-001 9379-202-001 9379-202-001 1
* Screw, Valve to Base 1/4ABx3/4 9545-030-002 9545-030-002 9545-030-002 9545-030-002 2
* Washer, Flat 1/4 8641-581-018 8641-581-018 8641-581-018 8641-581-018 4
13 Hose, Drain Valve to Tube 9242-457-001 9242-457-001 9242-457-001 9242-457-001 1
* Clamp, Hose (Drain Valve to
Tube
8654-117-014 8654-117- 014 8654-117-014 8654-117-014 2
14 Tube Assy, Drain 9915-124-002 9915-124-002 9915-124-002 9915-129-002 1
15 Clamp, Hose (Tube to Frame
Bracket)
8654-117-014 8654-117- 014 8654-117-014 8654-117-014 1
* Bracket, Drain Tube 9029-067-002 1
* Screw Tube (Bracket to Base
1/4Bx3/4)
9545-030-002 9545-030-002 9545-030-002 9545-030-002 4
16 Hose, Overow Tub To Drain
Tube
9942-449-002 9942-449-003 9942-449-003 9942-449-005 1
* Clamp, Hose 8654-117-018 8654-117-018 8654-117-018 8654 -117-018 1
* Tube, Suds overow 9242-463-004 9242-463-004 9242-463-004 9242-463-006 1
* Clamp, Hose 8654-117-008 8654-117- 0 08 8654-117- 008 8654-117-008 2
17 Hose, Pressure switch 9242-175-004 9242-175-007 9242-175-007 9242-175-004 1
Clamp, Hose 8654-117-015 8654-117-015 8654-117- 015 8654-117-015 1
Chassis and Drain Part # by Model
126
Part # 8533-093-001 1/18
