Dexter Laundry T650 - Electrical Components - Top Compartment

Key Description T650 T750 T950 T1450 QTY
1 Trough Assy,Controls 208-240 volt (all parts
below #2-#43 & trough)
9857-220-001 9857-205-001 9857-206-002 9857-208-001 1
* Trough only 9839-018-001 9839-018-001 9839-018-001 9839-017-001 1
* Screw, Trough Sides 9545-008-026 9545-008-026 9545-008-026 9545-008-026 4
* Lockwasher Exttooth #10 8641-582-006 8641-582-006 8641-582-006 8641-582-006 4
2 Spreader-Chanel, Trough 9081-136-001 9081-136-001 9081-136-001 9081-136-001
* Screw, Mtg #8Bx1/4” 9545-008-026 9545-008-026 9545-008-026 9545-008-026 4
3 Transformer, Control (Secondary Voltage to 115
volts)
8711-004-001 8711-004-001 8711-004-001 8711-004-001 1
* Screw, Mtg #8Bx1/4” 9545-008-026 9545-008-026 9545-008-026 9545-008-026 4
* Lockwasher 8641-582-006 8641-582-006 8641-582-006 8641-582-006 4
4 Screw GRN. #10-32x 1/2” 9545-008-027 9545-008-027 9545-008-027 9545-008-027 1
5 Lockwasher #10 8641-582-006 8641-582-006 8641-582-006 8641-582-006 1
6 Lug, Grounding 8652-130-037 8652-130-037 8652-130-037 8652-130-037 1
7 PCB assembly Relay Main 9473-006-001 9473-006-001 9473-006-001 9473-006-001 1
* Support, Edge Holding 9548-285-001 9548-285-001 9548-285-001 9548-285-001 6
* Harness, P17 Drain/Therm/Sol 9627-796-002 9627-796-002 9627-796-002 9627-796-002 1
* Harness P19/Water Valve 9627-795-004 9627-795-004 9627-795-004 9627-795-004 1
* Harness P8/P16 9627-794-0 01 9627-794-001 9627-794- 001 9627-794-001 1
* Harness P20/P21 9627-793- 001 9627-793-001 9627-793-001 9627-793-001 1
* Bushing , Wire 7/8 9053-067-002 9053-067-002 9053-067-002 9053-067-002 2
* Stando Twistlock 9527-002-002 9527-002-002 9527-002-002 9527-002-002 3
8 Terminal Block Assy, POWER 9897-026-004 9897-026-004 9897-026-004 9897-026-004 1
* Screw, Mtg 8Bx3/8” 9545-045-012 9545-045-012 9545-045-012 9545-045-012 2
9 Switch, Pressure 9539-457-004 9539-457-004 9539-457-002 1
* Screw, Mtg #8Bx1/4” 9545-045-001 9545-045-001 9545-045-001 2
* Harness P5/Pressure Switch 9627-908-008 9627-908-010 9627-908-012 9627-908-014 1
* Kit-Pressure Sensor, Electronic (10-12b) 9732-314-001 9732-314-001 9732-314-001 9732-314-001 1
10 Kit-Repaacement, Pressure Sensor (only) 9732-315-001 9732-315-001 9732-315-001 9732-315-001 1
10a Support-PCB, 3/8”, Edge Holding 9458-285-001 9458-285-001 9458-285-001 9458-285-001 1
11 Transformer-120/18VAC, 5 VA 8711-015-001 8711-015-001 8711-015-001 8711-015-001 1
12 Screw, 8B x 1/4 9545-045-001 9545-045-001 9545-045-001 9545-045-001 1
12a Wire Assy BLK/BLU 8220-001-233 8220-001-233 8220-001-233 8220-001-233 1
12b Wire Assy RED/BLU 8220-001-232 8220-001-232 8220-001-232 8220-001-232 1
13 Transformer, (Step Down) 120/24VAC 50/60hz 8711-009-004 8711-009-004 8711-009-004 8711-009-004 1
* Screw, Transformer Mtg #10Bx1/2” 9545-045-001 9545-045-001 9545-045-001 9545-045-001 4
* Lockwasher #10 exttooth 8641-582-005 8641-582-005 8641-582-005 8641-582-005 4
14 Fuseholder 9200-001-002 9200-001-002 9200-001-002 9200-001-002 1
* Fuse 1.5 amp 8636-018-001 8636-018-001 8636-018-001 1
* Fuse 2.5 amp 8636-018-004 1
15 Label Fuse 1.5 amp Rear 8502-716-001 8502-716- 001 8502-716-0 01 1
15 Label Fuse 2.5 amp Rear 8502-716-002 1
16 Angle Support Trough 9081-178-001 9003-278-001 9003-271-001 1
* Screw, Trough Bracket 9545-008-026 9545-008-026 9545-008-026 9545-008-026 4
17 Chanel-Support, Trough 9081-171-001 9081-172-001 9081-172-001 9081-172-001 1
* Screw, Mtg #8Bx1/4” 9545-008-026 9545-008-026 9545-008-026 9545-008-026 4
18 Chanel 9081-108-002 9081-108-002 9081-108-001 9081-155-001 1
* Screw, Mtg #8Bx1/4” 9545-008-026 9545-008-026 9545-008-026 9545-008-026 2
Electrical Components - Top Compartment
128
Part # 8533-093-001 1/18
