Dexter Laundry T650 - Water Inlet Part # by Model

Key Description T650 T750 QTY
1 Channel Assembly, Rear 9947-032-001 9947-027-001 1
2 Screw, #10B x 1/2 9545-008-026 9545-008-026 6
* Clip, Spring nut 8640-399-004 8640-399-004 6
3 Mounting Plate Water Valves 9452-813-001 9452-813-001 1
4 Nut-Hes Keps, #10-32, 2B 8640-413-002 8640-413-002 2
5 Valve, Water Inlet (dual outlet) (see Water Inlet
Valve Breakdown for individual parts)
9379-183-012 9379-183-012 2
6 Screw, Valve Mtg 9545-008-026 9545-008-026 4
7 Wire-Assy, Jumper, Yellow 8220-123-001 8220-123-001 1
8 Shield over Water Valves Plastic 9550-194-001 9550-194-001 1
9 Push Clip 9083-121-001 9083-121-001 3
10 Vacuum Breaker 9610-001-001 9610-001-001 1
* Bracket, Vacuum Breaker 9029-077-001 9029-077-001 1
11 Screw, #10B x 1/2 9545-008-026 9545-008-026 4
* Clamp, Hose to Vacume Braker 8654-117-014 8654-117- 014 1
* Hose, Vacuum Breaker to Tub 9242-458-003 9242-458-003 1
* Clamp, Tub End 8654-117-009 8654-117-009 1
12 Hose, Valve to Vac. Braker 9242-453-020 9242-453-020 4
* Hose, Cold, Vac. Brkr. dispenser 9242-453-013 9242-453-013 1
* Hose, Hot, Vac. Brkr. dispenser 9242-453-007 9242-453-007 1
13 Clamp, Hose-Worm 8654-117-015 8654-117-015 12
14 Hose, overow Suds 9242-450-002 9242-450-002 4
* Clamp, Hose-Spring (overow to tub back) 8654 -117-018 8654-117-018 2
15 Plate Assembly, Drive Mounting 9982-383-001 9982-383-001 1
16 Nut-#10-32UNF, 2B 8640-413-002 8640-413-002 8
17 VFD Delta “E drive 208-240 volt 9375-030-013 9375-028-010 1
* Key Pad-Display Delta “E” Drive 9150-044-001 9150-044-001 1
18 Cable-Data, Communication 9806-015-001 9806-015-001 1
19 Bushing, 7/8 9053-067-002 9053-067-002 1
20 Plug, 7/8 9545-041-006 9545-041-006 1
21 Bracket, Terminal-Mounting 9029-265-001 9029-265-001 1
22 Screw, #10B x 1/2 9545-008-026 9545-008-026 4
23 Label-Warning 8502-639-001 8502-639-001 1
24 Strip-Terminal Marker 9558-025-001 9558-025-001 1
25 Terminal Block 9897-033-002 9897-033-002 1
26 Screw-Phillips, 6ABx3/4 9545-031-010 9545-031-010 2
27 Harness-Power, Terminal Block 9627-747-003 9627-747-003 1
28 Bushing, 1” 9053-067-004 9053-067-004 1
29 Terminal Lug, Solderless 8652-134-001 8652-134-001 1
30 Lock-Washer, 1/2 8641-582-006 8641-582-006 1
30 Screw, #10-32 TTX 1/2 GRN 9545-008-027 9545-008-027 1
31 Bushing, 3/4 9053-067-001 9053-067-001 1
32 Braking resistors (200 ohm) 9483-004-002 9483-004-002 2
33 Screw-#10Bx1/2 9545-008-026 9545-008-026 4
Water Inlet & Rear Channel
116
Part # 8533-093-001 1/18
