Dexter Laundry T650 - Rear View Access Part # by Model

Key Description T650 T750 T950 T1450 QTY
1 Drive Motor, 3 Phase 9376-319-001 9376-329-001 9376-329-001 9376-326-001 1
2 Rod, Motor Mtg 9497-222-004 9497-222-004 9497-222-004 9497-222-004 1
3 Motor-Bushing, Support 9053-082-001 9053-082-001 9053-082-001 9053-082-001 2
4 Clamp for motor bushing 8654-117-019 8654-117-019 8654-117-019 8654-117-019 2
5 Pulley, Motor 9453-170-003 9453-179-001 9453-175-002 9453-175-002 1
Set, Screw 9545-028-015
5 Split TaperBushing (motor pulley) 9053-077-001 9053-077-001 2
* Screw taper bushing 1/4-20x1 9732- 9545-018-024 9545-018-024 3
6 Bolt, Eye (1/4”-20x1/2”) 9545-055-001 9545-055-001 9545-055-001 9545-055-001 1
* Nut, 1/4 Elastic Stop 8640-414-003 8640-414-003 8640-414-003 8640-414-003 1
* Link (open end) 9341-046-001 9341-046-001 9341-046-001 1
7 Chain (Spring Tension) 9099-012-003 9099-012-003 9099-012-004 1
* Bracket Belt Tension, Mounts on Moter 9029-206-001
* Nut, 10-32 8640-413-002
8 Spring, Belt Tension 9534-151-000 9534-151-000 9534-151-000 9534-151-000 1
9 Pulley, Driven 9453-173-002 9453-173-002 9453-176-005 9453-176-005 1
* Tollerence Ring 9487-234-004 9487-234-004 1
10 Screw, 5/8”-11 x 2” 9545-060-004 9545-060-004 1
11 Washer-Flat, 5/8” 8641-582-032 8641-582-032 1
12 Washer-Flat, 5/8” 8641-582-018 8641-582-018 1
10 Washer-Flat .675x2-1/2x1/4 8641-581-043 1
11 Lockwasher-Exttooth, 5/8 8641-582-018 1
12 Bolt, 5/8-11x1 1/2 9545-060-001 1
10 Washer-Flat, .781x2-1/2x1/4 8641-581-044 1
11 Lockwasher-Exttooth, 3/4 8641-582-020 1
12 Bolt, 3/4 -10 -1 1/2 9545-057-004 1
13 Bushing Taperlock (Pulley) 9053-078-002 9053-078-002 1
14 Bolt, 3/8”-16 x 2” 9545-029-011 9545-029-011 3
15 Washer, 3/8” 8641-582-003 8641-582-003 3
16 Drive Belt 9040-079-002 9040-079-006 1
16 Drive Belt 9040-076-005 9040-076-008 2
17 Hose, Overow to drain 9242-449-002 9242-449-003 9242-449-003 9242-449-005 1
* Clamp, Hose overow to drain 8654-117-018 8654-117-018 8654-117-018 8654-117-018 2
18 Hose, Overow Vent Top 9242-463-004 9242-463-004 9242-463-004 9242-463-006 1
* Clamp, Hose Vent 8654-117-008 8654-117-008 8654-117-0 08 8654-117-008 1
* Vaccum Breaker ALL 9610-001-001 9610-001-001 9610-001-001 9610-001-001 1
* Clamp, Hose to Vacuum Breaker 8654-117- 014 8654-117-014 8654-117-014 8654-117-014 2
19 Hose, Vacuum Breaker to tub 9242-458-003 9242-458-003 9242-458-003 9242-458-003 1
* Vaccum Breaker Bracket 9029-077-001 9029-077-001 9029-077-001 9029-266-001 1
* Cap, Fill 0935-135-002 0935-135-002 2
20 Hose, Pressure Switch 9242-175-004 9242-175-007 9242-175-007 9242-175-004 1
* Clamp, Pressure Switch Hose 8654-117-015 8654-117-015 8654-117-015 8654 -117-015 1
21 Channel, Rear, 9947-032-001 9947-027-001 9947-028-001 9947-029-001 1
22 Screw #10Bx1/2 9545-008-026 9545-008-026 9545-008-026 9545-008-026 4
* Nut, Spring 8640-399-004 8640-399-004 8640-399-004 8640-399-004 4
23 Cover, Terminal Block 9074-267-001 9074-267-001 9074-267-001 9074-267-001 1
* Screw #10Bx1/2 9545-008-026 9545-008-026 9545-008-026 9545-008-026 1
Rear View Access Part # by Model
108
Part # 8533-093-001 1/18
