Dexter Laundry T650 - Page 119

Key Description T950 T1450 QTY
30 Braking resistors (200 ohm) 9483-004-003 9483-004-003 2
31 Screw-#10Bx1/2 9545-008-026 9545-008-026 4
32 Wire Assy, Jumper 8220-117-002 8220-117-002 2
33 Screw, #6-32x5/16 9545-044-006 9545-044-006 4
33 Nut, #6-32 8640-411-003 8640-411-003 4
* Cover Controls 9074-267-001 9074-267-001 1
* Screw-#10Bx1/2 9545-008-026 9545-008-026 1
* Label-Warning, Notice 8502-761-0 01 8502-761- 001 1
1
9
2
6
5
4
3
10
20
19
18
17
16
15
14
13
8
12 11
7
21
22
26
25
24
23
30
33
28, 29
32
31
27
2
4
13
119
Part # 8533-093-001 1/18
