Dexter Laundry T650 - Page 132

Labels and Diagrams
Key Description T650 T-750 T950 T1450 QTY
* Wiring Diagram and Schematic,
Coin
9506-707-001 9506-535-001 9506-537-001 9506-541-001 1
* Transient Voltage Surge Sup-
pressor Infomational
8507-330-001 8507-330-001 8507-330-001 8507-330-001 1
* Label High Voltage Warning 8502-614-004 8502-614-004 8502-614-004 8502-614-004 1
* Label Fusing & Installation 8502-619-004 8502-619-003 8502-619-003 8502-619-008 1
* Label Quality 8511-001-002 8511-001-002 8511-001-002 8511-001-002 1
1 Label Warning Door Opening
(Blue)
8502-757-002 8502-757-002 8502-757-002 8502-757-002 1
1 Label Warning Door Opening
(Black)
8502-757- 001 8502-757-0 01 8502-757-0 01 8502-757-001 1
2 Label Warning Risk of Injury
(Blue)
8502-759-002 8502-759-002 8502-759-002 8502-759-002 1
2 Label Warning Risk of Injury
(Black)
8502-759-001 8502-759 -001 8502-759-001 8502-759-001 1
3 Label Dispenser (Blue) 8502-756-002 8502-756-002 8502-756-002 8502-756-002 1
3 Label Dispenser (Black) 8502-756-001 8502-756-001 8502-756- 001 8502-756 - 001 1
* Booklet Owners 8514-256-001 8514-229-001 8514-229-001 8514-231-001 1
