PCH-FW Configuration
This section only displays the parameters of Management Engine Technology.
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
ME FW Version
ME Firmware Mode
ME Firmware Type
ME Firmware SKU
PTT Capability/State
Advanced
9.5.30.1808
Normal Mode
Full Sku Firmware
5MB
1/0
 Select Screen
 Select Item
Enter: Select
+/
-:
Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
NCT6106D Super IO Configuration
This section is used to configure the I/O functions supported by the onboard Super I/O chip.
OS Select
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
Super IO Confi guration
Super IO Chip
OS Select

Serial Port 1 Confi guration

Serial Port 2 Confi guration

Serial Port 3 Confi guration
Advanced
NCT6106D
[Windows]
 Select Screen
 Select Item
Enter: Select
+/
-:
Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Enable or Disable Serial
Port (COM)
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
Serial Port 1 Confi guration
Serial Port
Device Settings
Change Settings
RS485 Auto Flow
Advanced
[Enabled]
IO=3F8h; IRQ=4;
[Auto]
[Disabled]
OS Select
Select the OS support: Windows or Linux/DOS.
Serial Port 1 Configuration to Serial Port 3 Configuration
Set the parameters of serial port 1 (COM A) to serial port 3 (COM C).
