Chapter 3 BIOS Setup
Chapter 3
Serial Port
Enables or disables the serial COM port.
Change Settings
Selects the IO/IRQ settings for the super I/O device.
RS485 Auto Flow
Sets the RS485 auto flow of the serial COM port.
Enable or Disable Serial
Port (COM)
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
Serial Port 2 Confi guration
Serial Port
Device Settings
Change Settings
RS485 Auto Flow
Advanced
[Enabled]
IO=2F8h; IRQ=3;
[Auto]
[Disabled]
 Select Screen
 Select Item
Enter: Select
+/
-:
Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Enable or Disable Serial
Port (COM)
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
Serial Port 3 Confi guration
Serial Port
Device Settings
Change Settings
Advanced
[Enabled]
IO=3E8h; IRQ=11;
[Auto]
 Select Screen
 Select Item
Enter: Select
+/
-:
Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
