Hardware Installation
2.5.7 Audio
Front audio
Audio Jacks
The system board is equipped with 3 audio jacks at location CN3.
A jack is a one-hole connecting interface for inserting a plug.
• Line-out Jack (Lime)
This jack is used to connect external speakers for audio output
from the system board. Using this jack disables the front audio’s
line-out function.
Surr_con
"
"
1
Mic
Mic Power
AuD_R_Out
N. C.
AuD_L_Out
GND
AuD_Vcc
Key
210
9
AuD_R_Return
AuD_L_Return
SL
Ground
SR
Ground
Ground/JS
Center out
Center Out Return
LFE Out
LFE Out Return
Key
1
9
2
Line-out
Line-in
Mic-in
"
