Hardware Installation
RJ45 LAN
2.5.6 RJ45 Fast-Ethernet Port (PS35-BL only)
The PS35-BL system board is equipped with an onboard RJ45 fast-
ethernet LAN port at location CN6 of the system board. It allows
the system board to connect to a local area network by means of a
network hub.
BIOS Setting
Enable or disable the onboard LAN in the Integrated Peripherals
submenu (“Onboard Device” field) of the BIOS. Refer to chapter 3
for more information.
Driver Installation
Install the “LAN Drivers” that is in the provided CD. Refer to
chapter 4 for more information.
"
