Hardware Installation
2.6.9 Chassis Fan and Second Fan Connectors
The chassis fan connector (J19) and second fan connector (J15) are
used to connect cooling fans. The cooling fans will provide adequate
airflow throughout the chassis to prevent overheating the CPU and
system board components.
Chassis fan
13
Ground
Power
N. C.
Second fan
!
!
31
Ground
Power
N. C.
