Install the
aircraft
28
Insta
llatio
n
NOTE
When this machine receives CAM data, it automatically changes the intensity of air pressure according to the
material to be processed.
1
Warning
Slowly and carefully turn the air pressure adjustment knob.
Otherwise, the machine may move suddenly and cause injury.
Important
Always set the air pressure to 0.4 MPa . 0.4 Exceeding MPa may result in failure. If the pressure is
small, sufficient effect cannot be obtained.
2. Set the air pressure
Procedure
1. Lift up the upper knob (pneumatic adjustment knob) ().
2. Adjust the air pressure
a. Slowly turn the top knob to adjust the air pressure to 0.3 MPa .
b. Slowly turn the top knob to increase the air pressure to 0.4 MPa .
• : Increase pressure
• : Lower the pressure
3. Lower the upper knob.
