Mass and Balance DA 42 AFM
Page 6 - 10 Rev. 8 15-Dec-2017 Doc. No. 7.01.05-E
6.4.3 CALCULATION OF LOADING CONDITION
NOTE
If the optional de-icing system (OÄM 42-053 or OÄM 42-054)
is installed, the following must be observed:
The consumption of fuel causes a forward movement of the
CG. The consumption of de-icing fluid causes a rearward
movement of the CG. Depending on the fuel flow and de-icing
fluid flow, the overall movement of the CG can be a forward
or a rearward movement. In order to cover all possible cases,
the following table must be completed twice: with (as shown
in the example) and without considering the on-board de-icing
fluid. All four CG positions (fuel tank full/empty, de-icing fluid
tank full/empty) must fall into the permitted area.
1. Complete the form on the next page.
2. Divide the total moments from rows 8 and 11 by the related total mass to obtain the
CG positions.
In our example: empty tanks: 3625.1 kgm / 1527.5 kg = 2.373 m
314,656 in.lb / 3368 lb = 93.43 in
full tanks: 4312.1 kgm / 1770.5 kg = 2.436 m
374,295 in.lb / 3904 lb = 95.87 in
3. Locate the values in the diagram in Section 6.4.4 - PERMISSIBLE CENTER OF
GRAVITY RANGE. If the CG positions and related masses fall into the permitted area,
the loading condition is allowable.
Our example shows allowable loading conditions (for 1785 kg take-off mass, i.e.,
MÄM 42-088 carried out).
