1.7 THREE-VIEW DRAWING
2950 mm
(9 ft 8 in)
18
7
0
mm
(
6
ft
2
i
n
)
13420 mm (44 ft 0 in)
1735 mm
8560 mm (28 ft 1 in)
2490 mm
(8 ft 2 in)
1950 mm
(6 ft 5 in)
2205 mm
(7 ft 3 in)
(5 ft 8 in)
13550 mm (44.5 ft) including ACL
