DA 42 AFM General
Doc. No. 7.01.05-E Rev. 8 15-Dec-2017 Page 1 - 7
1.4 DIMENSIONS
NOTE
All dimensions shown below are approximate.
Overall Dimensions
Span : 13.42 m 44.0 ft
13.55 m 44.5 ft including ACL
Length : 8.56 m 28 ft 1 in
Height : 2.49 m 8 ft 2 in
Wing
Airfoil : Wortmann FX 63-137/20 - W4
Wing area : 16.29 m² 175.3 sq.ft.
Mean aerodynamic chord : 1.271 m 4 ft 2 in
Aspect ratio : 11.06
Dihedral : 5°
Leading edge sweep : 1°
Aileron
Area (total, left + right) : 0.66 m² 7.1 sq.ft.
