General DA 42 AFM
Page 1 - 8 Rev. 8 15-Dec-2017 Doc. No. 7.01.05-E
Wing Flaps
Area (total, left + right) : 2.18 m² 23.4 sq.ft.
Horizontal Tail
Area : 2.35 m
2
25.3 sq.ft.
Elevator area : 0.66 m² 7.1 sq.ft.
Angle of incidence : -1.1° relative to longitudinal axis of airplane
Vertical Tail
Area : 2.43 m² 26.2 sq.ft.
Rudder area : 0.78 m² 8.4 sq.ft.
Landing Gear
Track : 2.95 m 9 ft 8 in
Wheelbase : 1.735 m 5 ft 8 in
Nose wheel : 5.00-5*
Main wheel : 15x6.0-6*
* for details refer to the Airplane Maintenance
Manual, Doc. No. 7.02.01, latest revision
