Diamond DA 42 - 6.4.4 Permissible Center of Gravity Range

DA 42 AFM Mass and Balance
Doc. No. 7.01.05-E Rev. 8 15-Dec-2017 Page 6 - 13
Flight Mass [kg]
1250 1300 1350 1400 1450 1500 1550 1600 1650
1700
1750 1800
Center of Gravity Positio
n [m]
2.35 2.40 2.45 2.50
F
l
i
g
h
t
M
a
s
s
[
l
b
]
Center of Gravity Positio
n [in]
9695949392 97 98
shaded area only for 1785 kg (3935 lb)
max. take-off mass (MÄM 42-088 carried out)
6.4.4 PERMISSIBLE CENTER OF GRAVITY RANGE
