DA 42 AFM Mass and Balance
Airplane Serial No.: Registration: Date: Mass Lever Arm
Description Type Part No. Manufacturer S/N inst‘d lbs kg in m
Doc. No. 7.01.05-E Rev. 8 15-Dec-2017 Page 6 - 25
Transponder antenna KA 61 071-00221-0010 Bendix/King
Marker antenna CI 102 Comant
GPS #1 antenna GA 56 010-10040-01 Garmin 0.400 0.180 104.100 2.645
GPS #2 antenna GA 56 010-10040-01 Garmin 0.400 0.180 104.100 2.645
DME KN 63 066-1070-01 Bendix/King 2.480 1.120 141.100 3.580
DME antenna KA 60 071-01591-0001 Bendix/King 0.220 0.100 91.930 2.335
DME antenna KA 61 071-00221-0010 Bendix/King
ADF receiver RA 3502-(01) 0505.757-912 Becker 2.080 0.940 155.500 3.950
ADF / RMI converter AC 3504-(01) 0856.010-912 Becker 1.300 0.590 165.400 4.200
ADF antenna AN 3500 0832.601-912 Becker 3.450 1.560 133.900 3.400
Stormscope WX-500 805-11500-001 L-3 (Goodrich) 2.290 1.040 140.100 3.560
Stormscope antenna NY-163 805-10930-001 L-3 (Goodrich) 0.820 0.370 280.700 7.130
TAS Processor TAS 600 70-2420-x TAS600 Avidyne/Ryan
TAS Processor TAS 605 70-2420-x TAS605 Avidyne/Ryan
TAS Processor TAS 610 70-2420-x TAS610 Avidyne/Ryan 6.800 3.100 164.300 4.175
TAS Processor TAS 615 70-2420-x TAS615 Avidyne/Ryan
TAS Processor TAS 620 70-2420-x TAS620 Avidyne/Ryan
TAS Processor 9900BX 70-2420-x Avidyne/Ryan
Transponder coupler 70-2040 Avidyne/Ryan 0.500 0.230 197.600 5.020
TAS antenna, top S72-1750-31L Sensor Systems 0.660 0.298 164.800 4.188
TAS antenna, bottom S72-1750-32L Sensor Systems 0.750 0.340 104.300 2.650
Data link processor GDL69A 011-00987-00 Garmin 2.490 1.130 159.400 4.050
GDL antenna GA 57 011-01032-00 Garmin 0.470 0.210 105.500 2.680
