DA 42 AFM Airplane Description
Doc. No. 7.01.05-E Rev. 8 15-Dec-2017 Page 7 - 13
Cockpit Ventilation
Ventilation in the front is provided by spherical ventilation nozzles (16) in the instrument
panel. Furthermore there are spherical nozzles in the roll bar on the left and right side
next to the front seats as well as on the central console above the passengers* heads.
The spherical nozzles are opened and closed by twisting.
Unconditioned ambient air is supplied to the interior through an inlet on the lower side
of the RH center wing stub. To increase cabin temperatures when operating at low outside
air temperatures, a winter kit - ventilation may be installed at the inlet.
The winter kit - ventilation consists of a metal plate with rubber edging and is attached
to the lower side of the RH center wing stub by a camloc.
