DA 42 AFM Airplane Description
Doc. No. 7.01.05-E Rev. 8 15-Dec-2017 Page 7 - 37
NOTE
The figure on previous page is a general demonstration of
a typical G1000 MFD to show the different display modes.
The pictured engine instrument markings may not stringently
agree with the current engine limitations of the DA 42.
NOTE
The fuel calculations on the FUEL CALC portion do not use
the airplane’s fuel quantity indicators. The values shown are
numbers which are calculated from the last fuel quantity
update done by the pilot and actual fuel flow data. Therefore,
the endurance and range data is for information only, and
must not be used for flight planning.
Designation Indication Unit
LOAD % Available power %
RPM Propeller RPM 1/min
FUEL FLOW Fuel flow US gal/hr
OIL TEMP Engine oil temperature °C
OIL PRES Oil pressure bar
COOLANT TEMP Coolant temperature °C
FUEL TEMP Fuel temperature °C
FUEL QTY GAL Fuel quantity US gal
VOLTS Volts V
AMPS Ampères A
GEARBOX Gearbox temperature °C
