DA 42 AFM Airplane Description
Doc. No. 7.01.05-E Rev. 8 15-Dec-2017 Page 7 - 69
7.13 GARMIN G1000 INTEGRATED AVIONICS SYSTEM
7.13.1 GENERAL
The Gamin G1000 is a fully integrated flight, engine, communication, navigation and
surveillance instrumentation system. This Integrated Avionics System consists of a Primary
Flight Display (PFD), a Multifunction Display (MFD), an Audio Panel, an Attitude and
Heading Reference System (AHRS), an Air Data Computer (ADC) and the sensors and
computers to process flight and engine information for display to the pilot. The system
contains dual GPS receivers, dual VOR/ILS receivers, dual VHF communications
transceivers, a transponder, and an integrated annunciation system to alert the pilot of
certain abnormal conditions.
A remote avionic box is located behind the aft baggage compartment frame. A push-to-talk
(PTT) button for the COM portion of the G1000 is mounted on the end of each control
stick. There are connection facilities for up to 4 headsets between the front seats.
Refer to the Garmin G1000 Cockpit Reference Guide, Garmin P/N 190-00406-( ), latest'
effective issue and Pilot*s Guide, P/N 190-00649-( ), latest effective issue for complete'
descriptions of the G1000 system and operating procedures.
NOTE
Near the DME ground station, it can happen under certain
adverse conditions that the Bendix/King KN 63 DME loses
the direct signal from the ground station and locks onto an
"echo". This will result in an inaccurate indication of the
distance.
NOTE
During retraction and extension of the landing gear the
ADF-indication may be inaccurate.
