DA 42 AFM Operating Limitations
Doc. No. 7.01.05-E Rev. 8 15-Dec-2017
EASA
approved
Page 2 - 11
If the TAE 125-02-99 engine is installed (MÄM 42-198 carried out):
Indi-
cation
Red
arc/bar
=
lower
prohibited
range
Yellow
arc/bar
=
caution
range
Green
arc/bar
=
normal
operating
range
Yellow
arc/bar
=
caution
range
Red
arc/bar
=
upper
prohibited
range
RPM -- --
up to
2300 RPM
--
above
2300 RPM
Oil
pressure
below
1.0 bar
1.0 to 2.3 bar 2.3 to 5.8 bar 5.8 to 6.5 bar
above
6.5 bar
Oil
temp.
below
-30 °C
-30 to 50 °C 50 to 130 °C 131 to 140 °C
above
140 °C
Coolant
temp.
below
-30 °C
-30 to 60 °C 60 to 101 °C 102 to 105 °C
above
105 °C
Gearbox
temp.
-- -- up to 115 °C 115 to 120 °C
above
120 °C
Load -- -- 0 to 100 % -- --
Fuel
temp.
below
-30 °C
-30 to +4 °C +5 to 69 °C 70 to 75 °C
above
75 °C
Ammeter -- -- up to 60 A --
above
60 A
Volt-
meter
below
24.1 V
24.1 to 25 V 25 to 30 V 30 to 32 V
above
32 V
Fuel qty. 0 US gal --
0 to 25
US gal
-- --
