Digi Connect ME Hardware Reference Manual

Module specifications
Network interface
Digi Connect ME/ME 9210 Digi Connect Wi-ME
n Standard: IEEE 802.3
n Physical Layer: 10/100Base-T
n Data Rate: 10/100Mbps (auto-
sensing)
n Mode: Half-duplex and full-
duplex support (auto-sensing)
n Connector: RJ-45
n Standard: IEEE 802.11b/Standard:
IEEE 802.11b/g/n
n Frequency: 2.4 GHz
n Data Rate: Up to 11 Mbps with
automatic fallback
n Modulation: CCK (11/5 Mbps),
DQPSK (2Mbps), DBPSK (1 Mbps)
n Transmit Power: 14 dBm typical
n Receive sensitivity:
l 1Mbps: -92 dBm
l 2Mbps: -89 dBm
l 5.5Mbps: -87 dBm
l 11Mbps: -82 dBm
n Antenna Connector: 1 x RP-SMA
CAUTION! The Digi Connect ME and Digi Connect Wi-ME embedded modules were
designed for use in no clean flux wave soldering processes. The product is not designed
to support draining after a water-wash process, which can lead to water residue inside
the enclosure resulting from direct entry or condensation after the wash process.
Serial interface
One TTL serial interface (CMOS 3.3v) with full modem control signals (DTR, DSR, DCD, RTS, CTS). The
Digi Connect ME 9210 also supports SPI and FIM-based application specific interfaces.
Digi Connect ME, Wi-ME, ME 9210, Wi-ME 9210 Hardware Reference Manual
40
