Digi Connect ME Hardware Reference Manual

Module specifications Mechanical specifications
Digi Connect ME, Wi-ME, ME 9210, Wi-ME 9210 Hardware Reference Manual
45
Mechanical specifications
Dimensions
Digi
Connect
ME
Digi Connect
Wi-ME
Length 1.445 in.
(36.703
mm)
1.85 in
(46.99 mm)
Width
0.75 in. (19.05 mm)
Height
0.854 in. (21.69 mm)
Weight .616oz.
17.463g
.696 oz.
19.731 g.
Antenna:.408
oz.
11.567 g
Total: 1.104 oz.
31.298 g
Device/serial
interface connector
20-pin micro header (10-pin double
row) with .05-inch (1.27-mm) pitch
(Samtec P/N FTS-110-01-F-DV-TR or
similar). Positions 3 through 6 are
removed.
Bar code
The 50m PN is code 3 of 9 (39) and the MAC is code 128. All scanners are set up so if they read code 3
of 9 they will automatically read 128. The reason for the two different code types is to maximize the
size of the bars within a given space to improved readability.
