Mic/DI Input Controls
There are four high-quality preamplifiers with
adjustable gain and phantom power (switchable
in pairs, for Inputs 1–2 and Inputs 3–4). The
phantom power switches are on the back panel.
Inputs 1–4 show up as “Analog 1–4” in the de-
fault Pro Tools I/O Setup.
Inputs 1–4 have the following controls:
Input 1–4 Gain Controls Each knob adjusts gain
for the input, with a range of +15 dB to +60 dB
of gain.
Mic/DI Switches (Inputs 1–4) Each switch tog-
gles the corresponding input between micro-
phone (unlit) or DI input (lit).
The DI/Mic switch LEDs indicate the current
source input. The LEDs blink rapidly when the
input is clipping.
HPF (High Pass Filter) Switches (Input 1–4)
These switches enable a high pass filter (75 Hz,
12 dB/octave rolloff) on the corresponding in-
put, for filtering out rumble or AC hum. The
HPF LEDs are lit when the HPF switch is enabled
(lit).
Monitor Section
The Monitor section provides the following
control room monitoring features:
Monitor and Headphone Level Controls
Headphone 1 and 2 Level Controls These knobs
control the volume of the independent Head-
phone Outputs. The Headphone Outputs nor-
mally mirror outputs 1–2 in Pro Tools, and are
independent of the Monitor Outputs.
Headphone 2 mirrors output pair 3–4 when the
3/4-HP2 switch is enabled (lit). Both head-
phones include Aux In signal when Aux In (to
monitor) is enabled.
Headphone output is not affected by the status
of the Monitor Mute switch, but does follow sta-
tus of the Mono switch.
Monitor Level Control These knobs control the
volume of the Main and Alt Monitor Outputs.
These outputs mirror Analog Outputs 1–2,
which correspond to outputs 1–2 in Pro Tools.
Alternate Input Routing Controls
Aux In to 7/8 Switch This switch routes the Aux
In input pair directly to Inputs 7–8 of Pro Tools,
and does not send it to the Main and Alt Moni-
tor Outputs. This lets you route an alternate in-
put signal (such as a CD player) directly into
Pro Tools without the need to repatch any ca-
bles.
When Aux In to 7/8 is enabled (lit), Analog In-
puts 7–8 are disabled.
3/4-HP2 Switch This switch sets Headphone 2
Output to mirror Output pair 3–4.
Engage the Mic switch only if you have an
XLR cable plugged into the mic connector.
Leaving the switch engaged with nothing
connected may introduce low-level noise.
