Digigram PYKO-out - 7 Specifications

PYKO-out: Professional IP audio endpoint
7. SPECIFICATIONS
Configuration
Size
140 mm x 41 mm x 145 mm (1/3 1U rack)
Power supply
24 VDC, +/- 20%
WARNING  Do not open the power supply module. It contains hazardous
voltages. There are no user-serviceable parts inside.
Temp / humidity
(non-condensing)
Operating:
Storage:
0 °C – 45 °C / 0% - 70%
-5 °C – 70 °C / 0% - 95%
Power requirements at
24 V
0.4 A
Net weight
0,477 kg (∼1.05 lb)
Outputs
Analog audio (mono)
2 outputs
Impedance
50 Ω
Connectivity
Audio
2x3 pins on terminal block
Ethernet port
RJ45 10/100-bit.
GPIO
4 GPIs compatible TTL
4 relay GPOs
on 2x8 pins on terminal block
Serial port
1 RS232 on DB9
USB
USB 1.1 interface for memory stick (FAT16)
1 port on front panel, 1 internal port (exclusive!)
Audio specifications
Sampling frequencies
available
Programmable from 8 to 48 kHz
A/D and D/A converter
resolution
24 bits
Supported audio formats
PCM (16 bits)
