PYKO-out: Professional IP audio endpoint
1. OVERVIEW
Contents of this package
The package consists of the following components:
● a PYKO-out device
● a counterpart for the power connector
Also available (optionally):
● Power supply with cable and connector mounted.
● Adaptor for mounting the PYKO-in on a DIN rail
● Adaptor for mounting the PYKO-in in a 19” rack
You have just acquired a Digigram IP ⬄ audio endpoint and we congratulate
you!
PYKO-out allows you to draw the most from an IP network in order to set up professional audio
installations.
The manual at hand will guide you through installation, configuration and use. For any software related
issue, please refer to the specific documentation provided in its on-line help.
For more information on PYKO applications, please refer to the document ‘Audio system cookbook’,
available on our web site.
2. KEY FEATURES
● 1/3 rack 1U, rackable with optional rail-din adaptor.
● 1 RJ-45 port (IP audio streaming, control & monitoring)
● 2 mono line-level balanced analog outputs on terminal blocks, max. +18 dBu max level
● 1 USB port on front panel, and one inside PYKO (only one of them can be used at a time), for local
storage of mp3 files and m3u playlist.
● RS232 port for ancillary data tunneling (typically RDS data), or for local control.
● 4 GPIOs on terminal block (for tunneling statuses PYKO, ru local control)
● One headphone output on front panel
● Decoding of RTP/UDP streams, as well as HTTP streams (Icecast / Shoutcast)
● Support of unicast and multicast addressing
● Support of the following audio formats: MPEG Layer 3, PCM, G711
● 3 decoding priorities (2 backup)
Priority 1: IP audio stream (RTP/UDP)
Priority 2: IP audio stream (RTP/UDP, HTTP), local playlist on USB memory stick
Priority 3: IP audio stream (RTP/UDP, HTTP), local playlist on USB memory stick
● Automatic priority switching upon IP stream loss
● Administration through WEB pages
● Supervision: SNMP, SYSLOG
5
