T4CK
T4CKR
T4CKR<3:0>
0010 = RPB8
0011 = RPB15
0100 = RPD4
0101 = RPB0
0110 = RPE3
0111 = RPB7
1000 = Reserved
1001 = RPF12
1010 = RPD12
1011 = RPF8
1100 = RPC3
1101 = RPE9
1110 = Reserved
1111 = RPB2
IC2
IC2R
IC2R<3:0>
IC5
IC5R
IC5R<3:0>
U1CTS
U1CTSR
U1CTSR<3:0>
U2CTS
U2CTSR
U2CTSR<3:0>
SS1
SS1R
SS1R<3:0>
Peripheral Pin
[pin name]R SFR
[pin name]R bits
[pin name]R Value to RPn Pin Selection
INT1
INT1R
INT1R<3:0>
0000 = RPD1
0001 = RPG9
0010 = RPB14
0011 = RPD0
0100 = RPD8
0101 = RPB6
0110 = RPD5
0111 = RPB2
1000 = RPF3
1001 = RPF13
1010 = Reserved
1011 = RPF2
1100 = RPC2
1101 = RPE8
1110 = Reserved
1111 = Reserved
T3CK
T3CKR
T3CKR<3:0>
IC1
IC1R
IC1R<3:0>
U3CTS
U3CTSR
U3CTSR<3:0>
U4RX
U4RXR
U4RXR<3:0>
U5RX
U5RXR
U5RXR<3:0>
SS2
SS2R
SS2R<3:0>
OCFA
OCFAR
OCFAR<3:0>
