Pin #
Full Pin Name
Peripheral
Schematic
Name
PPS
Function
55
RPF6/SCK1/INT0/RF6
SPI_FLASH
SPI_SCK
I/O
SCK1/U1RTS/U2RTS/OC1/OC2/INT
0
56
SDA1/RG3
I2C
SDA
SDA1
57
SCL1/RG2
I2C
SCL
SCL1
58
SCL2/RA2
LEDS
LED2
RA2
59
SDA2/RA3
LEDS
LED3
RA3
60
TDI/CTED9/RA4
LEDS
LED4
RA4
61
TDO/RA5
LEDS
LED5
RA5
62
VDD
POWER
VCC3V3
63
OSC1/CLKI/RC12
CLOCK
8MHZ
CRYSTAL
64
OSC2/CLKO/RC15
CLOCK
8MHZ
CRYSTAL
65
VSS
POWER
GND
66
RPA14/RA14
SSD
CB
I/O
RA14
67
RPA15/RA15
BUTTONS
BTND/S1_P
WM
I/O
RA15/OC4
68
RPD8/RTCC/RD8
PMOD
JB4
I/O
U1RTS/U2RTS/IC1/T3CK/INT1/OC1
/OC2
69
RPD9/RD9
PMOD
JB1
I/O
U1CTS/U2CTS/IC2/IC5/T4CK/INT2/
OC5
70
RPD10/PMCS2/RD10
PMOD
JB3
I/O
U1RX/U2RX/IC3/T2CK/INT3/OC3
71
RPD11/PMCS1/RD11
PMOD
JB2
I/O
U1TX/U2TX/IC4/T5CK/INT4/OC4
72
RPD0/RD0
PMOD
JB8
I/O
INT1/U5TX/IC1/T3CK/OC1/OC2
73
SOSCI/RPC13/RC13
PMOD
JB10
I/O
INT4/U5RTS/IC4/T5CK/OC4
74
SOSCO/RPC14/T1CK/RC14
PMOD
JB7
I/O
INT3/U5CTS/IC3/T2CK/OC3
75
VSS
POWER
GND
76
AN24/RPD1/RD1
PMOD
JB9
I/O
INT1/U5RX/IC1/T3CK/OC1/OC2
77
AN25/RPD2/RD2
RGB_LED
LED8_R
I/O
OC3/RD2
78
AN26/RPD3/RD3
RGB_LED
LED8_B
I/O
OC4/RD3
79
RPD12/PMD12/RD12
RGB_LED
LED8_G
I/O
OC5/RD12
80
PMD13/RD13
SSD
CG
RD13
81
RPD4/PMWR/RD4
LCD
DISP_EN
I/O
PMENB
82
RPD5/PMRD/RD5
LCD
DISP_R/W
I/O
PMRD/PMWR
83
PMD14/RD6
SSD
CC
RD6
84
PMD15/RD7
SSD
CF
RD7
85
VCAP
POWER
CAPACITOR
86
VDD
POWER
VCC3V3
87
RPF0/PMD11/RF0
BUTTONS
BTNC
I/O
RF0
88
RPF1/PMD10/RF1
MOTOR
MODE
I/O
RF1
89
RPG1/PMD9/RG1
IRDA
IR_PDOWN
I/O
RG1
90
RPG0/PMD8/RG0
ACCELEROM
ETER
ACL_INT2
I/O
INT4
