Appendix 1: Remappable Input Pins
Peripheral Pin
[pin name]R SFR
[pin name]R bits
[pin name]R Value to RPn Pin Selection
INT3
INT3R
INT3R<3:0>
0000 = RPD2
0001 = RPG8
0010 = RPF4
0011 = RPD10
0100 = RPF1
0101 = RPB9
0110 = RPB10
0111 = RPC14
1000 = RPB5
1001 = Reserved
1010 = RPC1
1011 = RPD14
1100 = RPG1
1101 = RPA14
1110 = Reserved
1111 = RPF2
T2CK
T2CKR
T2CKR<3:0>
IC3
IC3R
IC3R<3:0>
U1RX
U1RXR
U1RXR<3:0>
U2RX
U2RXR
U2RXR<3:0>
U5CTS
U5CTSR
U5CTSR<3:0>
REFCLKI
REFCLKIR
REFCLKIR<3:0>
Peripheral Pin
[pin name]R SFR
[pin name]R bits
[pin name]R Value to RPn Pin Selection
INT4
INT4R
INT4R<3:0>
0000 = RPD3
0001 = RPG7
0010 = RPF5
0011 = RPD11
0100 = RPF0
0101 = RPB1
0110 = RPE5
0111 = RPC13
1000 = RPB3
1001 = Reserved
1010 = RPC4
1011 = RPD15
1100 = RPG0
1101 = RPA15
1110 = RPF2
1111 = RPF7
T5CK
T5CKR
T5CKR<3:0>
IC4
IC4R
IC4R<3:0>
U3RX
U3RXR
U3RXR<3:0>
U4CTS
U4CTSR
U4CTSR<3:0>
SDI1
SDI1R
SDI1R<3:0>
SDI2
SDI2R
SDI2R<3:0>
Peripheral Pin
[pin name]R SFR
[pin name]R bits
[pin name]R Value to RPn Pin Selection
INT2
INT2R
INT2R<3:0>
0000 = RPD9
0001 = RPG6
