DG-GS1528HP/C User Manual
29
Figure 32 The VLAN port configuration page
7. SNMP Configuration
（1）SNMP share body configuration page
Figure 33 is a shared body of SNMP configuration page that allows users to configure the switch common body's
name and read and write access, A total of 8 entries can be configured
By default, the switch there is a share name as public, the common body is read-only access. With this
correspondence, the activities of this page is only one entry, shared body names are public, access is read-only
access. When the switch through SNMP for network management, you need to configure a read-write permissions to
the shared body.

Digisol DG-GS1528HP/C Specifications

General

Type	Managed
Ports	28
Number of Ports	28
PoE Ports	24
PoE Standard	IEEE 802.3af/at
PoE Power Budget	370W
Switching Capacity	56Gbps
MAC Address Table	8K
Jumbo Frame	9KB
Power Supply	Internal
Input Voltage	100-240V AC, 50/60 Hz
Certifications	CE, FCC, RoHS
Power Consumption	400W (Max.)
Operating Temperature	0°C to 45°C
Storage Temperature	-40°C to 70°C
Humidity	10% to 90% non-condensing
Dimensions (W x D x H)	440 x 44 x mm
Port Type	Gigabit Ethernet
Forwarding Rate	41.67Mpps
