NCH02 User’s ManualDigital Dream Motion Controller Page -16
8: Manual Jog Distance in Step Mode:
Each Axis can be jogged in defined distance.In Step Mode,you can define the increments by
0.01mm,0.1mm or 1mm.By turning the button,the values can be decrease or increase.
default Spindle Speed. The Default Spindle Speed can be changed, use the A- key to modify.
9: Feedrate:F stands for Feed Speed:
It is the minimum Feed speed value of the controller,can be adjust by Rotary button also.
If there is no F values in G-code file,the controller will run the file at the speed of Feedrate value,if there
is F value in G-code file,the controller just run as the G-code file.
10: Real time Feed Speed:
F Real-time Feed Speed Value shows the current feeding speed when running a G-code.
F Real-time Feed Speed Value=FRO*F(The Feed speed fixd by G-code or controller)
11: Speed of spindle:
It is the Default Spindle speed value of the controller,can be adjust by Rotary button also.
If there is no S values in G-code file,the controller will run the file at the speed of Feedrate value,if there
is S value in G-code file,the controller just run as the G-code file.
12: Real time Spindle Speed:
S Real-time Spindle Speed Value shows the current Spindle speed when running a G-code.
F Real-time Feed Speed Value=SRO*S(The Spindle speed fixd by G-code or controller).
13: M10/M11: Start/Stop of Lubrication
M10/M11 can adjust by rotaty button,or can run as the directive from G-code file.
14: M8/M9 : Start/Stop of Cooling
M8/M9 can adjust by rotaty button,or can run as the directive from G-code file.
15: M3/M4/M5: forward-rotating/Reverse-Rotating/Stop Spindle
M3/M4/M5 can adjust by rotaty button,or can run as the directive from G-code file.
16: Coordinate System
The Coordinate System Range is G54-G59,can adjust by rotaty button,or can run as the directive from
G-code file.
17: Controller System Status
There are 7 different kinds status of the controller.Here we explain them as below:
1
3
4
5
6
7
2
No. Display Definition
System Ready The Controller is Ready for Any Operation.
System Reset Controller is in Reset Status.
System is running The controller is running a G-code file
X(Y/Z)++ LIMITED
X(Y/Z)-- LIMITED
X(Y/Z)++ SOFT LIMITED
X(Y/Z)-- SOFT LIMITED Negative soft limit of X(Y/Z) is Triggered
Positive soft limit of X(Y/Z) is Triggered
Negative Limit of X(Y/Z) is Triggered
Positive Limit of X(Y/Z) is Triggered
