Digital Dream NCH02 User Manual

The NCH02 motion controller contains the handheld motion controller,wiring board,and HDMI digital
high-definition transmission cable.
The handheld motion controller and wiring board are communicated by 2 Meter 37 pins HDMI digital
high-definition transmission cable which is shielding twisted-pair cable to avoid interference.
Picture 1-1 shows the appearance and size of NCH02 Pendant.
Picture 1-2 shows the appearance and size of NCH02 Wiring Board.
1.3 Appearance, Structure and Size of Product
NCH02 User’s ManualPage -2Digital Dream Motion Controller
Picture 1-2 The NCH02 wiring board Size
70 mm
23.5 mm
100 mm
Picture 1-1 NCH02 Pendant Size
108 mm
30 mm
168 mm
23 User’s Keys
3.5’’ (480*320 ) LCD

Digital Dream NCH02 Specifications

General

Brand	Digital Dream
Model	NCH02
Category	Controller
Language	English
