Digital Dream NCH02 User Manual

Picture 1-3 shows the Installation size of NCH02 Wiring Board.
Picture 1-4 shows the 2 side pictures of NCH Wiring Board.The one side is for the MPG interface;and the
other side is the LED indicators and USB port for the communication with the NCH02 Pendant Controller.
There are two LED indicatiors,the red one is for the power,the green one is for the communications with
the NCH Pendant controller.
NCH02 User’s ManualDigital Dream Motion Controller Page -3
Picture 1-3
The NCH02 wiring board Install Size
Picture 1-4
The NCH02 wiring board 2 Sides Picture
The LED Indicatior and USB Port for the pendant The MPG Port
65 mm
4 mm
65 mm

Digital Dream NCH02 Specifications

General

Brand	Digital Dream
Model	NCH02
Category	Controller
Language	English
