NCH02 User’s ManualDigital Dream Motion Controller Page -21
4.3.4 Other Parameter Configuration(Others)
1
3
4
2
No. Mark Definition Range
Max Limit++_Ena
Limit++_Value
Limit--_Ena
Limit--_Value
1/0
0-10000
1/0
0-10000
Enable of Forward Direction soft limit,1:enable,0:disable
Soft limit position limit value at Forward Direction in mechanical coordinate system
Enable of Backward Direction soft limit,1:enable,0:disable
Soft limit position limit value at Backward Direction in mechanical coordinate system
13
15
16
14
No. Mark Definition Range
Home Spd
Language
Buzzer
EXT SIGNAL LEVEL
17 EXT SIGNAL PIN
0-100%
0
1/0
1/0
0-8
EnabHome speed ratio according to G0
Language settings (temporary support for English only)
Button buzzer switch, 0: close, 1: open
The pin of Estop,0 means close the signal,1=IN1,2=IN2.... 8=IN8.EXT Signal
effective for ESTOP/START/PAUSE/ZERO
Configuration of soft limit
5
7
8
9
10
11
12
6
No. Mark Definition Range
PROBE-PIN
PROBE-LEVEL
PROBE-MOD
P-X
P-Y
P-Z
P-B-Z
PROBE SPD
0-8
1/0
1/0
±10000
±10000
±10000
0-100
0-100%
The pin of Probe,0 means close the signal,1=IN1,2=IN2.... 8=IN8.
Electrical level of Probe, 1=high, 0=low
Electrical level of Estop, 1=high, 0=low.EXT Signal effective for ESTOP/START/PAUSE/ZERO
Probe mode, 0:fixed-position probe, 1:floating-position probe
X axis coordinate of Tool sensor in fixed-position mode
Y axis coordinate of Tool sensor in fixed-position mode
Z axis coordinate of Tool sensor in fixed-position mode
Back distance of Z axis after Probe in floating-position mode
Probe speed ratio according to G0
Configuration of Probe
Other parameter setting
