Digital Dream NCH02 User Manual

NCH02 User’s ManualDigital Dream Motion Controller Page -6
Picture 2-1
USB port
Picture 2-2 The Input Ports definition
As the following picture showed,by the USB terminal block is USB port, you can connect with handheld
controller.
As the Picture 2-1 showed, The power supply port.The Input voltage is 24VDC, and the power is not less
than 20W. The positive and negative connection of the power supply see as the silk printing.
2.1 USB Port
2.2 Main power supply port
2.3 The Input Ports
USB Port
GND
INP1
INP2
INP3
INP4
INP5
INP6
INP7
INP8
GND
12V
