page 5.12 Rev A September 2008
5. Userware Digital Projection TITAN User Manual
Image page
• To see the Image page, click on Image.
Component
• Click on Component to select one of the following from the drop down menu:
Component RGB
Component YUV
Phase slider
• Use the slider to adjust the Phase.
Notes
The Component selection is
available for the Component
input only.
For more information about
phase, see Picture menu and
Geometry menu, in section
4. Controlling the Projector.
The Phase slider is available for
RGB1 and RGB2 inputs only.
Component
Phase
slider
