SCART LEAD
SCART LEAD
TV SCART
VCR SCART
Connecting the TV and VCR
This section describes the methods when connecting both your TV and VCR to your product. Follow one of the
most appropriate methods described as below.
TV and VCR connections using the SCART leads are as below.
Using SCART Lead
1. On the RF OUT of the product and the aerial input of the VCR, use the RF lead connector for connection.
2. On the aerial output of the VCR and the aerial input of the TV, use the RF lead connector for connection.
Using RF Lead
ANTENNA OUTANTENNA IN ANTENNA IN
ANTENNA
VCR TV
RF LEAD
RF LEAD
13
