Spare Parts
Note: When ordering spare parts or accessories acc. to the table below
please always quote the type and the serial no. of the vacuum pump.
This will allow Busch service to check if the vacuum pump is compati
-
ble with a modified or improved part.
This parts list applies to a typical configuration of the vacuum pump
RA 0025 - 0040 F. Depending on the specific order deviating parts
data may apply.
Pos. Part Qty Part no.
1 Cylinder (RA 0025 F) 1 0223 137 428
1 Cylinder (RA 0040 F) 1 0223 137 410
14
Rotor with shaft sleeves
(RA 0025 F)
1 0950 138 501
14
Rotor with shaft sleeves
(RA 0040 F)
1 0950 138 493
22 Vane (RA 0025 F) 3 0722 000 270
22 Vane (RA 0040 F) 3 0722 000 300
24
Cylinder cover A-side,
complete
1 0952 138 010
27 Cylinder cover B-side, complete 1 0952 138 011
42 Supporting washer 2 0391 000 016
43 Hex head screw 4 0410 000 023
46 Seal ring 1 0484 000 029
47 Plug 1 0415 000 002
50 O-ring 2 0486 000 537
53 Hex head screw/lock washer 6 0947 127 451
57 Parallel pin 1 0437 138 870
60 Taper pin 4 0437 000 070
65 Parallel key 1 0434 000 019
66 Parallel key 1 0434 000 019
75
Oil separator (version with float
valve and oil return line)
1 0266 137 346
75
Oil separator (version with oil
return valve)
1 0266 138 692
78 Expanded metal 1 0534 000 924
79 Demister 1 0534 000 289
83 Sight glass 1 0583 000 001
84 Gasket 1 0480 000 271
88 Plug 1 0710 000 009
89 O-ring 1 0486 000 590
95 Plug 1 0710 000 010
96 O-ring 1 0486 000 505
99 Nipple 1 0461 000 061
100 Oil filter 1 0531 000 002
105 Cover 1 0320 109 603
106 Gasket 1 0480 000 153
107 Hex head screw/lock washer 4 0947 127 445
122 Exhaust filter with o-ring 1 0992 131 342
125 Filter spring 1 0947 000 720
136 Round gasket-service cover 1 0486 114 368
138 Hex head screw/lock washer 4 0947 127 447
139 Service cover 1 0247 113 773
141 Gasket 1 0480 000 112
146 Hex head screw/lock washer 4 0947 127 445
155 Exhaust cover plate, complete 1 0947 125 296
159 Exhaust valve, complete 2 0916 126 769
185 Gasket 1 0480 000 150
186 Stud bolt 4 0412 104 730
187 Spring lock washer 4 0432 000 012
191 Hex nut 4 0420 000 035
195 Oil return line, complete 1 0946 138 688
200 Float valve, complete 1 0947 138 417
210
Oil supply (RA 0025 F),
complete
1 0913 000 028
210
Oil supply (RA 0040 F),
complete
1 0913 000 026
250 Inlet flange, lower part 1 0246 101 999
255 O-ring 2 0486 000 526
257 Valve insert, complete 1 0916 125 491
260 Inlet flange 1 0246 000 541
261 Screen 1 0534 000 018
265 Hex head screw/lock washer 4 0947 127 453
280 Oil return valve, complete 1 0946 139 037
300 Motor flange 1 0247 107 490
301 Hex head screw/lock washer 3 0947 127 451
310
Coupling, complete, for 3phase
motor, motor shaftØ 19 mm
1 0510 000 006
310
Coupling, complete, for 3phase
motor, motor shaftØ 24 mm
1 0510 000 008
310
Coupling, complete, for AC
motor, motor shaftØ 24 mm
1 0510 000 504
310
Coupling, complete, for AC
motor, motor shaftØ 28 mm
1 0510 000 505
310 couplings for other motors 1 on request
312 Coupling sleeve, for AC motor 1 0512 000 003
312
Rubber coupling insert, for AC
motor
1 0512 000 109
315 Protection clip 3 0710 109 012
321 Axial flow fan (RA 0025 F) 1 0524 120 370
321 Axial flow fan (RA 0040 F) 1 0524 108 652
326 Locking ring 1 0432 000 367
340 Fan cover 1 0713 000 653
341 Tapping screw 2 0416 120 665
345 Protective grid 1 0713 110 795
391 Eye bolt 1 0416 000 001
400
3phase motor
0.75 kW, 230/400 V,
50 Hz, 1500 min-1,
shaftØ 19 mm
1 0612 000 918
400
3phase motor
0.9 kW, 190-210/380-420 V,
50 Hz, 1500 min-1;
1.1 kW, 190-240/380-480 V,
60 Hz, 1800 min-1,
shaftØ 24 mm
1 0613 129 386
400
3phase motor
1.1 kW, 230/400 V,
50 Hz, 1500 min-1,
shaftØ 24 mm
1 0614 127 186
400
3phase motor
1.1 kW, 208-230/380-460 V,
50/60 Hz, 1500/1800 min-1,
shaftØ 24 mm
1 0613 131 774
400
3phase motor
1.3 kW, 190-210/380-420 V,
50 Hz, 1500 min-1;
1.5 kW, 190-240/380-480 V,
60 Hz, 1800 min-1,
shaftØ 24 mm
1 0614 129 387
Spare Parts RA 0025 - 0040 F
page 20 0870139077 / 051214
