3 INTERNAL SETTINGS
3.1 PROCESSING MODULE
The processing module (MWTU) has configuration elements, the location of which can be
seen in Figure 6.
By carrying out a jumper between pin 1 of J7 and pin 1 of J8, the
IP address by default as well as the default user passwords are
loaded in the terminal, as indicated in Table 1.
Table 1 Default values activated when a jumper between
pin 1 of J7 and pin 1 of J8 is carried out
Figure 6 Location of the configuration elements of the MWTU module
(*)
The IP address in factory is the 172.16.6.3
