Quick Reference Guide
Figure 1
① The electrical information
regarding your electric replace
can be found on the rating label
located on the front of the unit,
behind the glass.
Please use our convenient online
registration page to record your
model and serial numbers for future
reference at
www.dimplex.com/register
② If you have any technical
questions or concerns regarding
the operation of your electric
replace, or require service
contact customer service.
③ For dimensions of your replace,
refer to Figure 1.
3" (7.6 cm)
50
5
16
" (128 cm)
19
1
2
(49.5 cm)
46" (116 cm)
48
1
2
" (123 cm)
7"
(17.8 cm)
3
13
16
"
(9.7 cm)
18"
(45.7 cm)
16"
(40.6 cm)
