6. FRONT PANEL KEYS AND INDICATORS (5 key version)
The front panel of the indicator is designed for quick and simple weighing applications. It consists of a display with 6 digits,
25 mm in height, 7 LED indicators (depending on the model), and a 5-key water-proof film keyboard.
If the indicator has an LCD display, while weighing, various multifunction symbols indicating the functioning status will turn
on (see section “SYMBOLS ON THE LCD DISPLAY”).
DFW LCD DISPLAY VERSION
DFW LED DISPLAY VERSION
1
2
1
2
3
4
5
6
7
8
