DFW series indicators DFW_03_12.07_EN_U
44
NOTE: the functionality of the MODE key is the same as the preceding way.
MASTER KEY MAP
Pressed key
3590 key
CPWE key
DGT key
ZERO
ZERO
F6
ZERO
TARE
TARE
TARE
TARE
MODE
RIGHT ARROW
F9
MODE
ENTER
E
NTER
ENTER
ENTER
C
C
C
C
1
1
1
1
2
2
2
2
3
3
3
3
4
4
4
4
5
5
5
5
6
6
6
6
7
7
7
7
8
8
8
8
9
9
9
9
0
0
0
0
POINT
SHIFT
POINT
NA
FN
F1
F1
F
NA: not available key
WARNING:
- To carry out the weight repeater function it is enough that just one SLAVE instrument in the system be turned on. When
turned on, the MASTER places itself automatically on the first turned on SLAVE (lowest 485 address); if all the
instruments are off or if the radio signal does not reach the MASTER, on the same display the “ECo n” message is
displayed in which n is the address of the SLAVE with which one is trying to communicate.
- If there are various slaves, it isn’t possible to transmit the functionality of the MODE key to the active slave.
- To carry out the sum function, it is necessary to have a connection with at least two SLAVES.
- In the sum mode, it isn’t possible to transmit the functionality of the ZERO, TARE, ENTER/PRINT and C keys to the
SLAVES.
- If the connection is lost with the SLAVE which is acting as a repeater, the MASTER will try to reconnect it; if after about
a second this does not happen, it connects with the following SLAVE.
- If the connection is lost with a SLAVE in the sum mode, the MASTER tries to reconnect it: if this happens, it remains in
the sum mode, otherwise it passes to the repeater mode of the following SLAVE.
11.6.4 EXECUTION OF THE PRINTOUTS
If there is a printer on the master:
- the printer has to be selected both in the SLAVE and in the MASTER (SEtuP >> SEriAL >> CoM.Prn >> Pr.ModE
parameter, TECH.MAN.REF.)
- it’s possible to direct on it the printouts and the heading configured in the active slave, by pressing on the MASTER or on
the SLAVE the dedicated key (depending on the selected function on the SLAVE). In order to configure this format refer
to section “PROGRAMMING THE PRINTOUTS”, TECH.MAN.REF.
- by pressing the ENTER/PRINT key when the sum is displayed, it is possible to execute a printout with the weighs of all
the detected scales and their sum. In order to configure this format refer to section “PROGRAMMING THE
PRINTOUTS”, TECH.MAN.REF.; the heading is the one programmed in the MASTER
If there is a printer on a slave:
- the printer has to be selected in the SLAVE (SEtuP >> SEriAL >> CoM.Prn >> Pr.ModE parameter, TECH.MAN.REF.)
but not in the MASTER
- it is possible to execute the printout configured in the SLAVE
