Dini Argeo DFWL - HORIZONTAL TOTALIZER (Sum of Lots) (Tot O)

DFW series indicators DFW_03_12.07_EN_U
54
TABLE OF OPERATING PARAMETERS IN PEAK MODE
LENGTH
SAMPLINGS PER SECOND
ACQUIRED VALUES
MEDIATED VALUES
1
400
1
1
2
200
1
1
3
100
1
1
4
100
4
2
5
50
4
2
10
25
4
2
20
12
4
2
50
6
4
2
100
6
8
2
127
6
12
2
When enabling the PEAK mode, it’s possible that the displayed weight isn’t really the one on the scale. Greater the number
of samplings per second, and greater is the weight that can be shown on the display.
E.g. if 0.000Kg is on the scale and the sampling time is equal to 1, when the PEAK mode is enabled, 0.034Kg could be
displayed.
11.14 HORIZONTAL TOTALIZER (Sum of lots) (tot o)
Once the totalizer operating mode is selected, both horizontal (tot o) and vertical (tot S), is asked to set the follows
parameters:
(!) 000.000Min.WGttot o / tot S
MAX.WGt (!) 000.000
MAX.tot
(!) 00
Tot.Mod
(!) MAnuAL
(!) Auto
N.WEiGh
(!) no
(!) Yes
FrZ.tot
(!) no
(!) Yes
Wait.St
(!) 000
CPS.tAr
(!) no
(!) Yes
Min.WGt: MINIMUM WEIGHT TO ACCEPT FOR TOTALIZE.
Minimum weight that must be present over the load receptor in order to totalize.
MAX.WGt: MAXIMUM WEIGHT TO ACCEPT FOR TOTALIZE.
Maximum weight that must be present over the load receptor in order to totalize.
MAX.tot: NUMBER OF CONSECUTIVE TOTALISATIONS AFTER WHICH THE TOTAL IS AUTOMATICALLY PRINTED
AND RESET
After having carried out the set weighs, the accumulated general total is printed and reset; set a value between 0 and 63.
NOTE: the value 0 disables the function
tot.Mod: TYPE OF TOTALISATION (MANUAL or AUTOMATIC)
This step allows to set the type of totalization: manual (MAnuAL) or automatic (Auto); with ZERO or TARE one changes the
parameter; with ENTER/PRINT one confirms.
- In the manual totalisation, for each accumulation operation there is the display of the “totAL” message and then of the
