Dini Argeo DFWL - Nineteen-Key Ir Remote Control; Six-Key Rd Remote Control

DFW series indicators DFW_03_12.07_EN_U
33
KEY ”none”MODE FUNCTION ”ir 18” MODE FUNCTION
ZERO
DISABLED
ZERO
TARE
DISABLED
TARE
MODE
DISABLED
MODE
PRINT
DISABLED
ENTER/PRINT
Fn
DISABLED
Fn
C
DISABLED
C
NUMERIC
KEYS
DISABLED
Numeri
c k
eys
By pressing at length the C key, it’s possible to put the instrument in stand-by; by pressing C on the keyboard or any key
on the remote control one returns to the weighing mode.
9.8.3 NINETEEN-KEY IR REMOTE CONTROL
NOTE: indoor use only.
If the model is provided for the 19-key remote control, it is possible to remotely use the functionality of the ZERO, TARE,
MODE, ENTER/PRINT, Fn, C/DEL and numeric keys.To choose this type of remote control follow the below procedure:
- Turn on the scale; press the TARE key while the firmware version is displayed (the display shows the “typE” menu).
- Press ZERO many times (to scroll ahead through the parameters) or TARE (to scroll backwards) until one finds the
“F.ModE” parameter.
- Press ENTER/PRINT to enter the menu.
- Scroll until one finds the “ir.ConF” parameter and select it.
- With the ZERO or TARE keys select the possible options: “none” (disabled remote control), “ir 19” (19-key remote
control is enabled)
All other options refer to other types of remote controls.
- Confirm with ENTER/PRINT.
- Press the C key many times until the message “SAVE?” appears on the display.
- Press ENTER/PRINT to confirm the changes made or another key to not save.
The remote control keys repeat the keys’ functions (both the ones obtained with a SHORT pressing as well as those with a
LONG pressing) and they correspond to the following indicator keys:
KEY ”none” MODE FUNCTION ”ir 19” MODE FUNCTION
ZERO
DISABLED
ZERO
TARE
DISABLED
TARE
MODE
DISABLED
MODE
PRINT
DISABLED
ENTER/PRINT
C
DISA
BLED
C
NUMERIC KEYS
DISABLED
Numeric keys
F1
DISABLED
Fn
F2
DISABLED
Not managed
F3
DISABLED
Not managed
By pressing at length the C key, it’s possible to put the instrument in stand-by; by pressing C on the keyboard or any key on
the remote control one returns to the weighing mode.
9.8.4 SIX-KEY RD REMOTE CONTROL
If the model is provided for the 6-key remote control, it is possible to remotely use the functionality of the ZERO, TARE,
MODE, ENTER/PRINT, C/DEL and Fn keys.
To choose this type of remote control follow the below procedure:
-
Turn on the scale; press the TARE key while the firmware version is displayed (the display shows the “typE” menu).
- Press ZERO many times (to scroll ahead through the parameters) or TARE (to scroll backwards) until one finds the
“F.ModE” parameter.
- Press ENTER/PRINT to enter the menu.
