9.8 REMOTE CONTROL (OPTIONAL)
If the model is supplied for the remote control, it is possible to remotely control the instrument through four different remote
controls: 4-key infrared (ir) remote control, 18-key infrared (ir) remote control, 19-key infrared (ir) remote control, or 6-key
radio (rd) remote control.
9.8.1 FOUR-KEY IR REMOTE CONTROL
NOTE: indoor use only.
If the model is supplied for the 4 keys remote control, it is possible to remotely use the functionality of the ZERO, TARE,
MODE, ENTER/PRINT keys or just the TARE key. To choose which type of functioning follow the below procedure:
- Turn on the scale; press the TARE key while the firmware version is displayed (the display shows the “typE” menu).
- Press ZERO many times (to scroll ahead through the parameters) or TARE (to scroll backwards) until one finds the
“F.ModE” parameter.
- Press ENTER/PRINT to enter the menu.
- Scroll until one finds the “ir.ConF” parameter and select it.
- With the ZERO or TARE keys select the possible options: “none” (disabled remote control), “ir 1” (all the remote control
keys function as the TARE key) or “ir 4” (the remote control keys functions as ZERO, TARE, MODE and
ENTER/PRINT).
All other options refer to other types of remote controls
- Confirm with ENTER/PRINT.
- Press the C key many times until the message “SAVE?” appears on the display.
- Press ENTER/PRINT to confirm the changes made or another key to not save.
In the “multifunction” configuration, the remote control keys repeat the keys’ functions (both the ones obtained with a
SHORT pressing as well as those with a LONG pressing) and they correspond to the following indicator keys:
KEY ”none”MODE FUNCTION ”ir 1” MODE FUNCTION ”ir 4” MODE FUNCTION
ZERO
DISABLED
TARE
ZERO
TARE
DISABLED
TARE
TARE
F1
MODE
DISABLED TARE MODE
F2
PRINT
DISABLED TARE ENTER/PRINT
In the “multifunction” configuration, by pressing at length the ZERO key, it’s possible to put the instrument in stand-by; by
pressing the C key on the keyboard or by pressing at length any key on the remote control one returns to the weighing
mode.
9.8.2 EIGHTEEN-KEY IR REMOTE CONTROL
NOTE: indoor use only.
If the model is provided for the 18-key remote control, it is possible to remotely use the functionality of the ZERO, TARE,
MODE, ENTER/PRINT, Fn, C/DEL and numeric keys.To choose this type of remote control follow the below procedure:
- Turn on the scale; press the TARE key while the firmware version is displayed (the display shows the “typE” menu).
- Press ZERO many times (to scroll ahead through the parameters) or TARE (to scroll backwards) until one finds the
“F.ModE” parameter.
- Press ENTER/PRINT to enter the menu.
- Scroll until one finds the “ir.ConF” parameter and select it.
- With the ZERO or TARE keys select the possible options: “none” (disabled remote control), “ir 18” (18-key remote
control is enabled)
All other options refer to other types of remote controls
- Confirm with ENTER/PRINT.
-
Press the C key many times until the message “SAVE?” appears on the display.
- Press ENTER/PRINT to confirm the changes made or another key to not save.
The remote control keys repeat the keys’ functions (both the ones obtained with a SHORT pressing as well as those with a
LONG pressing) and they correspond to the following indicator keys:
