DFW series indicators DFW_03_12.07_EN_U
7
Sense.
I/O SECTION DFW:
- 1 RS232/TTL input/output configurable for connection to PC/PLC or WEIGHT
REPEATER.
- 1 RS232 input/output for connection to printer.
DFWL, DFWLB, DFWLI, DFWLIB, DFWLKR, DFWLID:
- 1 RS232/TTL input/output
- 1 RS232/485 input/output
Configurable for connection to PC/PLC, WEIGHT REPEATER or PRINTER.
DFWLKRF:
- 868Mhz integrated radio modem for communication with the scale.
- 1 RS232 input/output for connection to printer.
DFWPM:
- 868Mhz integrated radio modem for communication with the scale.
- USB port (DFWPM10USB model)
DFWLAP:
- 868Mhz integrated radio modem for communication with the scale.
CLOCK DFW: optional, with battery.
DFWL, DFWLB, DFWLI, DFWLIB, DFWLKR, DFWLKRF, DFWPM, DFWLID,
DFWLIDCC: fitted internally (date and time stored for 5 minutes in case of power
supply disconnection or battery replacement), or external optional (with battery).
THE PARTS OF THE INSTRUMENT CONTAINING DANGEROUS ELECTRICAL TENSION ARE ISOLATED AND
INACCESSIBLE TO THE USER UNLESS IT HAS BEEN DAMAGED, OPENED, OR ALTERED.
3. SYMBOLS
To call the attention of the user, the following symbols are used both in the manual and on the instrument itself:
WARNING! This operation must be performed only by qualified personal.
Conforms to the standards of the European Union.
Identifies the Class Of Precision defined by the OIML to represent 3000 divisions
“TECH.MAN.REF.”
means that an advanced function is being described (therefore for the technical personnel) which
will be further explained in the corresponding technical manual.
