Dini Argeo DFWL - 17-Key Indicator Scale Key Functions

DFW series indicators DFW_03_12.07_EN_U
26
SCALE KEY
FUNCTION
ZERO
- Zeros the displayed gross weight, if it is within +/- 2% of the total capacity.
- Cancels the negative tare value .
- When entering numbers it decreases the digit to be modified.
TARE
- If pressed for an instant it carries out the semiautomatic tare.
- If pressed at length it allows entering the manual tare from keyboard.
- Cancels the negative tare value .
- In the numeric input phase it increases the digit to be modified.
MODE
- It carries out a specific function of the operating mode set in the set-up environment.
- In the numeric input phase it selects the digit to be modified, from left to right.
- In totalizator modes, if pressed twice consecutively, it allows to enter in a specific menu to
set the parameters of the totalizations.
ENTER / PRINT
- It carries out a specific function of the operating mode set in the set-up environment.
- In the numeric input phase, it confirms the entry made.
- In the SET-UP, it allows to enter a step or to confirm a parameter within a step.
- It transmits the data from the serial port dedicated to the printer.
C
- It turns the instrument on and off.
- In the numeric input phase, it quickly zeros the present value.
- In the set-up environment, it allows to exit a step without confirming the change made.
F / Fn
- It allows to select the desired function; see section “ADDITIONAL FUNCTIONS OF
THE 17-KEY INDICATOR”.
- If pressed at length it allows to set the display intensity (TECH.MAN.REF.), “L.int”
parameter).
i / .
- The “i” key allows to view the scale’s metric information: capacity, division, minimum
weigh for each configured range.
- In the numeric input phase it allows to enter the decimal point.
NUMERIC KEYBOARD
- In the numeric input phase it allows to enter the desired value.
