Platform: DBALL2
Firmware: CHRYSLER Remote Start Ready (RSR) Installation
© 2017 Directed. All rights reserved.
Rev.: 20170214
Drivers kick
harness to rear
(+) Parking Lights
White/ Violet
FT CAN High: Tan/Black: 3
FT CAN Low:White
or White/Pink ,
pin 7
FT CAN High:
White/Orange,
pin 6
1 8
Sentry Key Module
(black 8-pin conn.)
FT CAN Low: Tan: 4
(-) Ground: Black: 14
(+) 12V: Red: 13
(+) Ignition Output: Yellow: 8
(MUX) Ign. Output: Violet/Green: 8
(MUX) Ign. Output: Violet/Brown: 9
(-) P.K. Lights Output: Green/Black: 2
(+) 12V: Brown: 7
(+) 12V: Brown/Red: 12
(+) 12V: Red or
Red/Striped, pin 5
(-) Ground:
Black or
Black/Striped,
pin 4
HS CAN High: Orange/Green: 5
HS CAN Low: Orange/Brown: 6
Diagnostic Connector OBDII
(connector side view)
1 8
169
HS CAN High: Green, pin 6
HS CAN Low: Orange, pin 14
(MUX) Ignition:
Violet/Brown,
pin 1
(+) Ignition:
Pink or Pink/Stiped,pin 3
(-) RAP Off Output: Yellow/Black: 10
30
86
85
87
87a
To vehicle’s
(+) Parking Lights
Fuse 15A
+12V
Refer to the Vehicle Wiring Reference Charts for wire color and location.
(+) 12V
Refer to the Vehicle
wiring reference chart.
Driver Door Trigger
Refer to the Vehicle
wiring reference chart.
Installation Type 5 - without T-Harness
Page 16
With the exception of the OBDII Diagnostic connector, all adapters are displayed from the wire side (unless specified otherwise).
10
DBALL2
Prog. Button
LED
4
14 12 2
RF
6: White/Black: (-) Hood
Hood Pin
Remote Start Safety
Override Switch
You can connect to either a XL202
RFTD OR a SmartStart module.
Refer to the SmartStart/XL202
Installation Notes for more information.
