Type 5 - Vehicle Wiring Reference Chart
Function Color Pin Polarity Location Color Pins
Chrysler 200 2011-2014
FT CAN High White/Orange 6 Data Sentry Key Module near ignition switch. Black 8
FT CAN Low White 7 Data Sentry Key Module near ignition switch. Black 8
MUX Ignition Violet/Brown 1 MUX Sentry Key Module near ignition switch. Black 8
12V Red or Red/Striped 5 (+) Sentry Key Module near ignition switch. Black 8
Ground Black or Black/Striped 4 (-) Sentry Key Module near ignition switch. Black 8
HS CAN High White/Lt/Blue 6 Data OBDII diagnostic connector. Black 16
HS CAN Low White/Dk.Blue 14 Data OBDII diagnostic connector. Black 16
Parking Lights White/Violet N/A (+) Driver kick panel. N/A N/A
Parking Light Relay power Red 3 (-) Junction connector above drivers kick panel. Green 43
Driver Door Trigger Violet 14 (-) Under driver dash. Lt.Gray 43
Chrysler Aspen 2007-2009
FT CAN High White/Orange 6 Data Sentry Key Module near ignition switch. Black 8
FT CAN Low White 7 Data Sentry Key Module near ignition switch. Black 8
MUX Ignition Violet/Brown 1 MUX Sentry Key Module near ignition switch. Black 8
12V Red/Gray 5 (+) Sentry Key Module near ignition switch. Black 8
Ground Black or Black/Striped 4 (-) Sentry Key Module near ignition switch. Black 8
HS CAN High White/Pink 6 Data OBDII diagnostic connector. Black 16
HS CAN Low Pink/Red 14 Data OBDII diagnostic connector. Black 16
Parking Lights White/Violet N/A (+) Driver kick panel. N/A N/A
Parking Light Relay power Red/Gray 1 (-) Driver kick panel fuse box. Black 40
Driver Door Trigger Violet 14 (-) Under driver dash. Lt.Gray 43
Chrysler Sebring 2007-2010
FT CAN High White/Orange 6 Data Sentry Key Module near ignition switch. Black 8
FT CAN Low White 7 Data Sentry Key Module near ignition switch. Black 8
MUX Ignition Violet/Brown 1 MUX Sentry Key Module near ignition switch. Black 8
12V Red or Red/Striped 5 (+) Sentry Key Module near ignition switch. Black 8
Ground Black or Black/Striped 4 (-) Sentry Key Module near ignition switch. Black 8
HS CAN High Green 6 Data OBDII diagnostic connector. Black 16
HS CAN Low Orange 14 Data OBDII diagnostic connector. Black 16
Parking Lights White/Violet N/A (+) Driver kick panel. N/A N/A
Parking Light Relay power Red 4 (-) Junction connector above drivers kick panel. Green 43
Driver Door Trigger Violet 14 (-) Under driver dash. Lt.Gray 43
Chrysler Sebring Convertible 2008-2010
FT CAN High White/Orange 6 Data Sentry Key Module near ignition switch. Black 8
FT CAN Low White 7 Data Sentry Key Module near ignition switch. Black 8
MUX Ignition Violet/Brown 1 MUX Sentry Key Module near ignition switch. Black 8
12V Red or Red/Striped 5 (+) Sentry Key Module near ignition switch. Black 8
Ground Black or Black/Striped 4 (-) Sentry Key Module near ignition switch. Black 8
HS CAN High Green 6 Data OBDII diagnostic connector. Black 16
HS CAN Low Orange 14 Data OBDII diagnostic connector. Black 16
Parking Lights White/Violet N/A (+) Driver kick panel. N/A N/A
Parking Light Relay power Red 4 (-) Junction connector above drivers kick panel. Green 43
Driver Door Trigger Violet 14 (-) Under driver dash. Lt.Gray 43
Chrysler Sebring Sedan 2007-2010
FT CAN High White/Orange 6 Data Sentry Key Module near ignition switch. Black 8
FT CAN Low White 7 Data Sentry Key Module near ignition switch. Black 8
MUX Ignition Violet/Brown 1 MUX Sentry Key Module near ignition switch. Black 8
12V Red or Red/Striped 5 (+) Sentry Key Module near ignition switch. Black 8
Ground Black or Black/Striped 4 (-) Sentry Key Module near ignition switch. Black 8
HS CAN High Green 6 Data OBDII diagnostic connector. Black 16
HS CAN Low Orange 14 Data OBDII diagnostic connector. Black 16
Parking Lights White/Violet N/A (+) Driver kick panel. N/A N/A
Parking Light Relay power Tan/Red 4 (+) Junction connector above drivers kick panel. Green 43
Driver Door Trigger Violet 14 (-) Under driver dash. Lt.Gray 43
Dodge Avenger 2008-2014
FT CAN High White/Orange 6 Data Sentry Key Module near ignition switch. Black 8
FT CAN Low White 7 Data Sentry Key Module near ignition switch. Black 8
MUX Ignition Violet/Brown 1 MUX Sentry Key Module near ignition switch. Black 8
12V Red or Red/Striped 5 (+) Sentry Key Module near ignition switch. Black 8
Ground Black or Black/Striped 4 (-) Sentry Key Module near ignition switch. Black 8
HS CAN High Green 6 Data OBDII diagnostic connector. Black 16
HS CAN Low Orange 14 Data OBDII diagnostic connector. Black 16
Parking Lights White/Violet N/A (+) Driver kick panel. N/A N/A
Parking Light Relay power Red 4 (+) Battery or TIPM on passenger fender. N/A N/A
Driver Door Trigger Violet 14 (-) Under driver dash. Lt.Gray 43
Wire Information Connector Information
